5Hp Air Compressor Motor 3450 RPM 7/8" Shaft 230V 1 Phase 3450 RPM Frame-56 HZ
This page is affiliate-supported. Prices and availability can change after the last marketplace refresh.
About this product
This is a 5 HP air compressor motor with a 7/8-inch keyed shaft, designed to operate at 3450 RPM on a 230V single-phase power supply at 60 Hz. It features an ODP (Open Drip-Proof) enclosure and an F-class insulation (Max 311°F). The motor has a 56 HZ/143T IEC frame size, a service factor of 1.00, and a full load amperage of 21. It's base-mounted and manufactured in the United States.
Our take
This 5 HP air compressor motor is a solid, straightforward option for those needing a reliable replacement. With 3450 RPM and a 230V single-phase requirement, it aligns with many common compressor setups. The 7/8-inch keyed shaft ensures easy compatibility. The ODP enclosure is standard for motors in this price range, but remember it's best for controlled environments, not areas exposed to significant dust or moisture. The 1.0 service factor indicates it's designed for consistent operation at its rated load, without much capacity for overload. Class F insulation is a positive, offering good heat resistance.
Pros & Cons
Pros
- 5 HP rated load
- 3450 RPM base speed
- 7/8 inch keyed shaft
- 230V single-phase operation
- Class F insulation
Cons
- ODP (Open Drip-Proof) enclosure
- 1.00 service factor
Specifications
- Country of Origin United States
- Brand Handdo
- MPN 1029428
- Enclosure Type ODP (Open Drip-Proof)
- Current Type AC
- AC Phase Single Phase
Show all 20 specifications
- IEC Frame Size
- 56 HZ/143T
- Shaft Type
- Keyed
- Design
- Open Drip Proof (ODP)
- Shaft Diameter
- 7/8 in
- Model
- EM-05
- Rated Load (HP)
- 5
- Nominal Rated Input Voltage
- 230 V
- Service Factor
- 1.00
- AC Frequency Rating
- 60 Hz
- Mounting Type
- Base-Mounted
- Insulation Class
- F (Max 311°F)
- Base RPM
- 3450 RPM
- Full Load Amps
- 21
- Color
- Multi-Color
